Technics SL-EH560 User Manual

TE IC702-
33 pin
1.7 V
FOD IC702-
28 pin
1.7 V 1.7 V
TRD IC702-
27 pin
1.7 V 1.7 V
KICK IC702-
26 pin
- -
/FLOCK IC702-
11 pin
- -
/RFDET IC702-
38 pin
0 V 3.3 V
RF TJ701
1.0 V
STAT IC702-
17 pin
3.3 V 0 V
E04,
E06,
E0C,
E0E,
Best Eye
(PD
balance)
adjustment
not
completed
in the
specified
time period.
Scratches or
contaminants
on disc
surface.
Focus and
Tracking
servo circuit
(check
waveforms,
voltages and
part values.)
Optical
pickup.
FBAL IC702-
30 pin
1.7 V 1.7 V
RF IC701-8
pin
1.0 V
FE IC702-
32 pin
1.7 V
/TLOCK IC702-
12 pin
- -
OFT IC702-
36 pin
0 V 0 V
