Play switch (
)
S615:
Stop switch (
)
S616:
R.Skip/search switch (
)
S701:
Rest detect switch in OFF position
S790:
Disc tray close detect switch in OFF position
S791:
Disc tray open detect switch in OFF position
Indicated voltage values are the standard values for the unit measured by the DC electronic circuit
tester (high-impedance) with the chassis taken as standard. Therefore, there may exist some errors in
the voltage values, depending on theinternal impedance of the DC circuit tester.
No mark
: CD Stop
( )
: CD Play [1 kHz, L+R, 0 dB]
