30 STAT I Status signal input
31 HALH - CD mechanism motor speed control signal output (Not used, open)
32 PLG - CD mechanism solenoid control signal output (Not used, open)
33 CW O CD mechanism motor control signal output (forward direction)
34 CCW O CD mechanism motor control signal output (reverse direction)
35 PSTN - Position sensor detect signal input
(Not used, open)
36 SW1 - Disc tray position 1 detect signal input
(Not used, open)
37 SW2 - Disc tray position 2 detect signal input
(Not used, open)
38 SW3 I Disc tray open detect signal input
39 SW5 - Bottom switch detect signal input
(Not used, open)
40 KEY2 I Operation key signal input
41 KEY1 I Operation key signal input
42 SW4 I Disc tray close detect signal input
•@
