Technics SU-G700 Owner's Manual

34
Others
Specifications
■ GENERAL
Power supply AC 120 V, 60 Hz
Power
consumption
85 W
Power
consumption in
standby mode
Approx. 0.3 W
Dimensions
(W×H×D)
430 mm (16
15
/
16
”) ×
148 mm (5
13
/
16
”) ×
428 mm (16
27
/
32
”)
Mass Approx. 12.3 kg (27.2 lbs)
Operating
temperature range
0 °C to +40 °C
(+32 °F to +104 °F)
Operating humidity
range
35 % to 80 % RH
(no condensation)
■ AMPLIFIER SECTION
FTC output power
70 W + 70 W
(1 kHz, T.H.D. 0.5 %, 8 ,
20 kHz LPF)
140 W + 140 W
(1 kHz, T.H.D. 0.5 %, 4 ,
20 kHz LPF)
Load impedance 4  - 16 
Frequency
response
PHONO (MM)
20 Hz to 20 kHz
(RIAA DEVIATION ±1 dB,
8 )
LINE
5 Hz to 80 kHz
(-3 dB, 8 )
DIGITAL
5 Hz to 90 kHz
(-3 dB, 8 )
Input sensitivity/
Input impedance
PHONO (MM) 2.5 mV / 47 k
LINE 200 mV / 22 k
■ TERMINALS SECTION
Headphones Jack
Stereo, 6.3 mm (
1
/
4
”)
0.75 mW, 32 
PC
REAR USB
Type B Connector
Analog input
LINE IN ×2 Pin jack
PHONO (MM) Pin jack
Digital input
OPT IN ×2 Optical terminal
COAX IN ×2 Pin jack
Format support LPCM
Analog output
LINE OUT Pin jack
PRE OUT Pin jack
System port
System control  3.5 mm (
1
/
8
”), Jack
■ FORMAT SECTION
USB-B
USB Standard
USB 2.0 high-speed
USB Audio Class 2.0,
Asynchronous mode
DSD control mode
ASIO Native mode,
DoP mode
(34)

Technics SU-G700 Specifications

General

Type	Integrated Amplifier
Power Output (8Ω)	70 W + 70 W (1 kHz, T.H.D. 0.5%)
Power Output (4Ω)	140 W + 140 W (1 kHz, T.H.D. 0.5%)
Input Sensitivity/Impedance Line	200 mV / 47 kΩ
Input Sensitivity/Impedance Phono	2.5 mV / 47 kΩ
Speaker Impedance	4Ω - 16Ω
USB-B Input	Yes
Coaxial Input	1
Standby Power Consumption	0.3 W
Weight	12.3 kg
Signal-to-Noise Ratio Phono	83 dB (IHF-A)
Digital Inputs	Coaxial, Optical, USB-B
Analog Inputs	1 (Phono)
Analog Outputs	1 Line
Dimensions	430 x 148 x 428 mm
