Item Number
Component Description
Quantity
41
Spring
3
42
Adjusting Nut
3
43
Plunger
3
44
Valve cover
3
45
O-ring (Valve Cover)
3
46
O-ring (Stuffing Box)
3
47
Gasket
3
48
Gasket (Valve Cover)
3
49
Valve Cover Clamp
3
50
Hex Nut (Cylinder Cover Clamp)
6
51
Washer (Cylinder Cover Clamp)
6
52
Stud (Fluid Cylinder to Power End)
2
53
Stud (Fluid Cylinder to Power End)
6
54
Hex Nut (Fluid Cylinder Attachment)
2
55
Washer (Fluid Cylinder Attachment)
2
56
Stud (Valve Cover)
As Required
57
Washer (Valve Cover)
As Required
58
Nut (Valve Cover)
As Required
59
Cylinder Cover Clamp
3
60
Cylinder Cover
3
61
O-ring (Cylinder Cover)
3
62
O-ring, Suction Flange (For Flange config)
1
63
O-ring, Discharge Blind Flange (For Flange Config)
1
64
O-ring, Suction Blind Flange (For Flange Config)
1
65
O-ring, Discharge Flange (For Flange Config)
1
66
Suction Flange (For Flange Config)
1
67
Discharge Flange (For Flange Config)
1
68
Discharge Blind Flange (For Flange Config)
1
69
Suction Blind Flange (For Flange Config)
1
70
Nut, Discharge Flange (For Flange Config)
8
71
Stud, Discharge Flange (For Flange Config)
8
72
Stud, Suction Flange (For Flange Config)
8
73
Nut, Suction Flange (For Flange Config)
8
74
Front Foot
1
75
Pipe Plug (Drain, Fluid Cylinder)
As Required
76
Pipe Plug (Drain, Cast Fluid Cylinder)
1
77
Pipe Plug (Valve Cover, Cast Fluid Cylinder)
3
