TechniSat DIGIDISH 33 Installation Instructions

8
E N
Dear Customer
Thank you for choosing a quality product from TechniSat. To ensure that the quality of the
product remains unchanged over years of use, the mounting and dish are made from alumi-
nium.
The dish is designed to receive digital signals from the ASTRA satellites. To ensure optimal
reception after installation, please read the installation instructions carefully before installing.
Before sta
rting the installation, check that all of the parts for the external unit are present.
Parts supplied (see Figures 1 and 2)
1
A
A
2
3
4
B
C
5
6
D Screws for setting the
angle of elevation
Figure 1
Figure 2
Item Article
1 1 AZ/EL bracket with LNB clamp and swivel profile
2 1 Dish
3 1 Connector rod
4
1 Wall bracket*:
5 1 LNB
6 1 LNB clamp, 1 M6 x 40 bolt, 1 M6 x 16 bolt
A 4 M6 x 15 bolts, 4 M6 nuts, 4 washers
10m coaxial cable with F-connectors (only included with complete sets that
come with the receiver)
“short” “medium” “long”oror
* Contents depend on package selected

TechniSat DIGIDISH 33 Specifications

General

Package weight	3200 g
Material	Aluminum
Product color	Beige
Frequency range	10.7 - 12.75 GHz
Antenna gain level (max)	30 dBi

Weight and Dimensions

Width	330 mm
Height	350 mm
Weight	2500 g
