TechniSat DIGIPLUS UHD S User Manual

120
> Now select the desired filter option from the list that appears and confirm the
selection using the OK buon.
The channel list now only shows the channels that fit the desired criteria. In
order to filter the list further, follow the above steps again and set more filters
this way.
To remove all filters
> Open the Option menu using the OPT buon.
> Select the Filter option and press the OK buon.
> Now select [Reset all filters] and press the OK buon.
The full channel list is now displayed again.
11.3.6 Retrieving blocked channels
If a channel is selected that is blocked by the parental control function, the
messageDevice PIN will be displayed on the screen.
> Use the number buons to enter the device PIN.
The selected channel can now be viewed. Alternatively:
> Switch to a channel that is not blocked.
If global parental control is enabled, the device PIN code will be requested
again when the blocked channel is switched on. To make things easier for you,
you only need enter the PIN code once during each operating phase.
To do so, it is essential that you also observe the instructions and seings
regarding the global user-dependent parental controls (TechniFamily) in your
instruction manual.

TechniSat DIGIPLUS UHD S Specifications

General

Certification	CE
Package depth	195 mm
Package width	310 mm
Package height	80 mm
Package weight	1350 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Timer	Yes
Tuner type	Digital
Demodulation	8PSK, QPSK
Product color	Black
Interactive TV	-
Frequency range	950 - 2150 MHz
Number of tuners	2 tuner(s)
Audio output channels	- channels
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Signal source	Satellite
Supported video modes	576i, 576p, 720p, 1080i, 1080p, 2160p
Digital signal format system	DVB-S, DVB-S2
Audio formats supported	AAC, AIFF, FLAC, M4A, MP2, MP3, WAV
Image formats supported	BMP, GIF, JPEG, PNG
Video formats supported	ASF, AVI, M2TS, MKV, MOV, MP4, MPG, MTS, TS, TS4, VOB
Video compression formats	AVC, H.264, H.265, HEVC, MPEG1, MPEG2
Display type	LCD
Ethernet LAN data rates	1000 Mbit/s
AC input voltage	230 V
Power consumption	400 mA
AC input frequency	50 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	17.1 W
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Built-in HDD	No

Weight and Dimensions

Depth	175 mm
Width	220 mm
Height	40 mm
Weight	668 g
