TechniSat DIGIPLUS UHD S User Manual

94
7 Optional accessories
IsiZapper remote control
Item no. 0000/3773
The IsiZapper remote control is an optional remote control that is specially designed
to operate ISI mode.
TechniSat ISIO USB dual-band WLAN adapter
Item no. 0005/3633
Bluetooth dongle
Item no. 0000/3635
External infrared receiver
Item no. 0000/3615
8 DIGIPLUS UHD S connection
8.1 Remote control / Changing the baery
WARNING
Ensure that the baeries are kept out of the reach of children. Children could
put the baeries into their mouths and swallow them. This could lead to
serious injuries. Seek medical advice immediately if this occurs! Therefore
ensure that the baeries are out of reach of young children.
> Open the cover on the baery compartment on the back of the remote
control by pressing gently on the point indicated and pressing in the direction
of the arrow.
> Insert the supplied baeries, ensuring that the poles are the right way round
(indicator visible in baery compartment).
> Close the baery compartment again.
8.2 Connecting the satellite system
> Connect the LNB inputs 1 and 2 (6/7) using two separate antenna feed
cables that are set up identically to be able to use the full range of functions.
or
> If there is only one antenna signal available, connect this to LNB input 1 (6) on
the device.
> Also observe the section on Antenna seing in the instruction manual.
It is not possible to receive analogue TV!
> For operation with a rotating system, connect the DiSEqC motor (Level 1.2) to
LNB input 1.

TechniSat DIGIPLUS UHD S Specifications

General

Certification	CE
Package depth	195 mm
Package width	310 mm
Package height	80 mm
Package weight	1350 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Timer	Yes
Tuner type	Digital
Demodulation	8PSK, QPSK
Product color	Black
Interactive TV	-
Frequency range	950 - 2150 MHz
Number of tuners	2 tuner(s)
Audio output channels	- channels
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Signal source	Satellite
Supported video modes	576i, 576p, 720p, 1080i, 1080p, 2160p
Digital signal format system	DVB-S, DVB-S2
Audio formats supported	AAC, AIFF, FLAC, M4A, MP2, MP3, WAV
Image formats supported	BMP, GIF, JPEG, PNG
Video formats supported	ASF, AVI, M2TS, MKV, MOV, MP4, MPG, MTS, TS, TS4, VOB
Video compression formats	AVC, H.264, H.265, HEVC, MPEG1, MPEG2
Display type	LCD
Ethernet LAN data rates	1000 Mbit/s
AC input voltage	230 V
Power consumption	400 mA
AC input frequency	50 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	17.1 W
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Built-in HDD	No

Weight and Dimensions

Depth	175 mm
Width	220 mm
Height	40 mm
Weight	668 g
