TechniSat Switch Series

29
Protection type (housing) IP20
Measurement accuracy
(performance)
1 W - 10 W
10 W - 50 W
> 50 W
±0.3 W
±0.4 W
±3 %
Status LED Red = device is logged into the
network.
Flashing red = overload detected.
Green (5 seconds) = device
successfully logged in.
Z-Wave frequency
Transmission capacity
868.42 MHz
4 dBm
Ambient conditions
In operation
Temperature: +5 °C - +35 °C
Humidity: 10 % - 75 % RH
Ambient conditions
Storage & transport:
Temperature: -20 °C - +60 °C
Humidity: 5 % - 90 % RH
non-condensing
Dimensions (W x H x D) 70 mm x 70 mm x 45 mm
* Depending on the model, see label on page 1.
