TechniSat TECHNISTAR S6 User Manual

12
EN
3.6 Network port (RJ45)
Using the network port (9) you can connect the device to your existing network.
By doing so, you can, for example, use the Internet radio functionality or control the
device via the TechniSat CONNECT app.
To do so, also observe the Network seings section in your instruction manual.
3.7 Analogue Audio/Video connection
You can also operate the receiver on a TV or an external recording device with
analogue audio/video input. To do so, use the optionally available TechniSat specific
adapter set and connect it to the AV OUT (12).
4 Basic operation
Dear Customer,
The following section starts by covering basic operation as well as the recurrent steps
for operating the device. This should make it easier to read the quick start manual,
since it avoids repeated description of identical steps at each individual stage.
If a function or seing for the device needs to dier from the basic operation, the
dierence in operation is described in detail at the relevant point in the operating
manual.
The so-called "On Screen Display" (OSD) is used in your device. This simplifies the
operation of your device since the buons on the remote control can perform
dierent functions. This makes it possible to reduce the number of buons.
On this On Screen Display (OSD) the selected functions or seings can be
highlighted.
Furthermore, on the lower edge of the screen there is a line where individual buons
on the remote control are represented with their current functions. In this instruction
manual the terms shown in the OSD as well as the buons to be pressed are
distinguished from the rest of the text by the print format used.
Warning - indicates an important note which you absolutely should observe in
order to avoid problems with the device, loss of data or unwanted operation.
Tip - This identifies information relating to the described function, as well
as to another related function that may have to be taken into account, with
reference to the corresponding section in the manual.

TechniSat TECHNISTAR S6 Specifications

General

Signal source	Ethernet (RJ-45), Satellite
Supported video modes	576i, 576p, 720p, 1080i, 1080p
Digital signal format system	DVB-S, DVB-S2
Personal Video Recorder (PVR) included	-
Tuner type	Digital
Product color	Black
Number of tuners	1 tuner(s)
Audio output channels	- channels
On Screen Display (OSD)	Yes
Audio formats supported	AAC, AC3, AIFF, FLAC, MP2, MP3, OGG, WAV
Image formats supported	BMP, GIF, JPEG, PNG, TIFF
Video formats supported	ASF, AVI, M2TS, M4V, MKV, MOV, MP4, MPG, TS, TS4, XVID
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100 Mbit/s
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	4.8 W
Package weight	1240 g

Weight and Dimensions

Depth	177 mm
Width	220 mm
Height	45 mm
Weight	600 g
