7 Technical Specifications
7.1 General points
Model TECHNIVOLT 100 TECHNIVOLT 101
Item number: 0000/6400 0000/6401
EAN 4019588064003 4019588064020
IEC protection class Class l Class l
7.2 Input / power connection
Nominal voltage 230 / 400 V 230 / 400 V
Nominal current rating 16 A, 3-phase 16 A, 3-phase
Rated frequency 50 / 60 Hz 50 / 60 Hz
Power consumption on
standby
3.5 W 3.5 W
Mains infeed 5 x 4 mm (< 50 m), 15-21 mm dia. 5 x 4 mm (< 50 m), 15-21 mm dia.
7.3 Output / vehicle connection
Charging operating mode Mode 3, IEC61851-1 Mode 3, IEC61851-1
Charging connection Plug socket type 2, IEC-62196 Charging cable 5m with type 2
coupling. IEC-62196-2
Output voltage 230 / 400 V 230 / 400 V
Maximum charging current 16 A per phase 16 A per phase
Maximum charging power 11 kW 11 kW
7. 4 Fuses
DC residual current detection RCM internal, I
n
≥ 6 mA RCM internal, I
n
≥ 6 mA
Line protection switch (MCB)
in input / power connection
Trigger characteristics C
For details, see Chapter 10.1
Trigger characteristics C
For details, see Chapter 10.1
Ground fault circuit interrupter
(RCCB) in input/power
connection
4P-20A-30mA, type A 4P-20A-30mA, type A
7.5 Authorisation
RFID ISO-14443A/B and ISO-15693 ISO-14443A/B and ISO-15693
7.6 Communication
Data interface RS484, Modbus RS484, Modbus
7. 7 Mechanical properties
Casing material Plastic, flame-resistant Plastic, flame-resistant
Bushing for mains infeed M32, for cable 15-21 mm dia. M32, for cable 15-21 mm dia.
Bushing for data cable M20, for 2 cables Ø M20, for 2 cables Ø
Weight device 4.315 kg
Device dimensions 315 mm (width) x 460 mm (height)
x 135 mm (depth)
315 mm (width) x 460 mm
(height) x 135 mm (depth)
Weight, including packaging 6.315 kg
Packaging dimensions 398 mm (width) x 520 mm (height)
x 237 mm (depth)
398 mm (width) x 520 mm
(height) x 324 mm (depth)
7.8 Operating conditions
Protection class IP54 IP54
Impact resistance IK10 IK10
Temperature -35 °C to 55 °C (without direct
sunlight)
-35 °C to 55 °C (without direct
sunlight)
