Technische Alternative UVR 16x2 User Manual

Time switch
126
Output variables
Time condition status
Status of the time switch function ON/OFF taking into consideration
the derivative time, dwell time and blocking function
Set value (1 – 2)
Issue of the current set values 1 / 2
Minimum timer
Display of the elapsed minimum time for the blocking function
Blocking timer
Display of a countdown of the blocking time
Effective time window
Status ON when the time window applies, even if the blocking function
sets the time condition status to OFF.
The derivative time and dwell time extend the time condition status, so
the "Effective time window" will be ON in those periods as well.
Time window
As with "Effective time window", but not taking into consideration
the derivative time and dwell time
➢ If enable OFF is selected, the time condition status, the effective time window and the
time window are also OFF.
➢ Set value (1 -2):
o If the Number of set values has been set to 0, the output for both set values will be
0.
o If set values have been defined for the current time window, those values will be
issued during the time window. Outside the time window, the parameter values Set
value (1 -2) if time prog. = Off will be issued.
o If no set values have been defined in the current time window, then the parameter
value Set value (1 -2) if time prog. = Off will always be issued.
o The value in Set value (1 -2) if time prog. = Off will be issued during the blocking
time, even if the time window is active.
o When Enable is OFF the Set value (1 – 2) (enable = off) input variables will be
issued.
o If several time windows with different set values overlap, then the highest value from
these set values is applied.
