Conservatory function
158
Output variables
Open/close window
Window drive status OPEN/OFF/CLOSE; selection of the output pair
for the window drive
Window 0 - 100 %
A percentage value to one decimal place, for control of a window drive
with 0-10 V input via an analogue output (O12- O16)
Effective conservatory set
temp.
Display of the current set conservatory temperature including offset
value
Auto mode status
Status ON if function is in auto mode
Remaining runtime ctr
Display of a countdown of the remaining double runtime set at the
output pair
Interval timer
Display of a countdown of the interval time
Window open
Status ON when the window is fully open (at end of remaining
runtime)
Window closed
Status ON when the window is fully closed (at end of remaining
runtime)
No rain
Status ON if the window drive has been enabled by the rain sensor
and the remaining runtime has elapsed.
Rain block counter
Display of a countdown of the blocking time in seconds
Wind speed < max.
Status ON if the window drive has been enabled by the wind sensor
and the remaining runtime has elapsed.
Wind block counter
Display of a countdown of the blocking time in seconds
➢ Once the accumulated runtime of the window has reached twice the runtime set at the
output pair, the output will no longer be activated in that direction. The remaining runtime
counter will display 0, and the Window open or Window closed display will have the status
ON.
➢ If shutdown is activated by the wind or rain sensor, the interval time changes to twice the
runtime. Opening the window when the shutdown condition has ended is not possible until
the window is completely closed (remaining runtime counter = 0, window closed status =
ON) and the blocking time has elapsed.
➢ Window drive 0 - 100 %: Scaling of the analogue output: 0 = 0.00 V / 1000 = 10.00 V
➢ If Enable = OFF, then 30 °C will be issued as the effective set conservatory temperature.
➢ A changeover from manual to auto mode can only be brought about by an On pulse on
Trigger auto mode, simultaneous actuation of Open window and Close window or by the
time exceeding the time set in Switching to auto mode at.
