Shading function
39
Parameters
Slats
Blinds: enter Yes
Roller shutters: enter No
Width (shown only if slats:
Yes)
Enter the slat width in mm (see Figure 1)
Clearance (shown only if
slats: Yes)
Enter the distance between slats in mm (see Figure 1)
Slats horizontal at
Enter the percentage for horizontal slat position
Window settings
Cardinal direction
Diff. on
Diff. off
Enter the cardinal direction of the window (see Figure 2):
North = 0°
East = 90°
South = 180°
West = 270°
Correction of the start time due to building characteristics
(see Figure 2)
Correction of the stop time due to building characteristics
(see Figure 2)
Solar altitude correction
Option for manual correction of the slat position
Minimum solar altitude
If the sun is below the minimum solar altitude, the function will act
according to the if max. solar altitude switching condition (see
Figure 3)
Maximum solar altitude
If the sun is above the maximum solar altitude, the function will act
according to the if max. solar altitude switching condition (see
Figure 3)
Shading settings
Interval time
Enter the minimum time interval between two changes of slat
position
Switching conditions
if enable = off
Action of the function if enable = OFF
if enable auto mode =
off
Action of the function if enable auto mode = OFF
if shading area end
Action of the function if the sun moves out of the shading area
if max. solar altitude
Action of the function if the sun stands above the maximum solar
altitude or below the minimum solar altitude
➢ If "Slats: No" is set (= roller shutter), only the upward/downward movement will be
regulated, not the slat positioning.
➢ Switching conditions: These parameters define the output signal for blind control of the
respective function states.
Available for selection: Open, Close, Unchanged, set horizontally
