Techroutes TSR 2900-10 User Manual

TSR2900-10 Hardware Installation Manual
- 11
3.3.2 Connecting Gigabit Ethernet Ports
TSR2900-10 provides 8 10/100/1000Mbps Base-T ports, 2 1000M combo ports and
UTP(RJ45) ports with ACT, Link indicators. In use, the ports can connect other Ethernet
terminal devices through the UTP port. The numbering order of the pins in the UTP
port is the same as the console port. See the following figure:
RJ45 Connector of the console port
10/100/1000Mbps ports - HUB linking figure
Pins of UTP port:
No.
Pin name
Abbrev
1
Receiving and
sending the normal
phase of the data 0
TP0+

Techroutes TSR 2900-10 Specifications

General

Brand	Techroutes
Model	TSR 2900-10
Category	Network Router
Language	English
