TSR2900-10 Hardware Installation Manual
- 3
5
AC power input port
Input voltage: 170～264V,
frequency: 47～63Hz
Current: 1A/230V
1.2 Systematic Characteristic Parameters
CPU
Cavium CN7020
Memory
1GB
Nor Flash
32M
Nand Flash
8Gbit
Standard
configuration
2 1000M Ethernet optical and Base-T comb ports（WAN）
2 1000M Ethernet Base-T ports (WAN)
8 1000M Ethernet (LAN)
1 Console port
1 USB interface
1 RESET button
Packet forwarding
rate
1.4Mpps
Dimensions mm
(W×D×H)
300*200*44
Weight（Kg）
Power consumption
（W）
36W (12V/3A)
Installation
Desktop, rack-mounted
Dissipation
Cooling fin + Complete air cooling
Operating
temperature/
humidity
0℃～40℃; 10%～85% non-condensing
Storage
temperature/
humidity
-20℃～65℃；5%～95% no
n-condensing
