Hardware Specifications
Core Processor Dual CPUs (400Mhz DSP, 180Mhz ARM Processor)
Display
65K Color 2.8” TFT LCD with backlight
Lifetime: 10 years
Keypad 0~9, Enter, ESC, 4 Function keys
External Interface
I/O Ports
RJ45 Ethernet TCP/IP (Between VP-II Xs and/or Server)
Wiegand (Input: 1, Output: 1)
Serial port: 2 channel
RS232 only: 1
RS232/RS485 shared: 1 (Optional RS485 module required)
Digital I/O (Input: 2, Output: 2)
Memory
512Mbytes NAND Flash memory built-in
Up to 50,000 Users database
Up to 500,000 logs(User transactions and/or system events)
Firmware, GUI, Font, etc storage
USB 2.0
USB Memory device (Firmware upgrade, DB transfer)
Can be activated only when authorized by an administrator
Optional use: Wireless LAN, External key board
Card Module
Card reader module installed inside (Optional)
125Khz Prox. reader
13.5Mhz Mifare / DESFire / TWIC / PIV
13.5Mhz HID iClass
Only one type out of above three can be installed
Built-in antenna for 125KHz and 13.5Mhz
RTC (Real Time Clock) Automatic adjustment function for time accuracy
Speaker Sound/Voice supported
IR Sensor User detection, Awake from sleep mode
Tamper Switch Installed on the rear cover
