TecMate Optimate 4 User Manual

PRODUCT INFORMATION
Certification / Conformity
Holder: TecMate (International ) S.A. , B-3300 Tienen, Belgium
Issued by: TUV SUD Product Service GmbH, DE (Safety and EMC)
Safety (CE-LVD) : Low voltage directive 2006/95/EC; EN 60335-2-29:2004/A2:2010;
EN 60335-1:2012/A11:2014;
EN 62233:2008
Safety (NRTL) : UL 1236:R2011; CAN/CSA C22.2 no. 107.2-01 (R2011)
Safety (SAA) : AS/NZS 60335.2.29:2004 Inc A1-2; AS/NZS 60335.1.2011 Inc A1
EMC (CE) : EMC Directive 2004/108/EC; EN55014-1/A2:2011; EN55014-2/
A2:2008; EN61000-3-2/A2:2009; EN6100-2-2:2013
EMC (NRTL) : FCC CFR Title 47 Part 15 Subpart B
Efficiency - BC
mark
(California
Energy Commision)
CEC-400-2012-011-CMF; 10 CFR Section 430.23 (aa) Appendix Y to
Subpart B of Part 430.
Tests by: Mantek International Canada Inc, Oakville ON, Canada.
Listed models: TM34x, TM35x
Energy usage: Not charging: P < 0.5W Long term maintenance: P < 0.5W ( < 0.012
kWh / day, < 4.4 kWh / year )
Mechanical
IP rating IP54
t° operating range -40°C <-> 40°C / -40°F <-> 104°F
Weight (packed) 0.48kg (0.9kg) / 1.05lbs (1.98 lbs)
Size without cable 200 x 75 x 61mm / 7.87" x 2.95" x 2.40"
Cable Length Input: 183cm / 72" Output: 183cm / 72"
Wall mount 4 mount positions
Accessories O-09 BIKE (DIN) Adapter - Extender; O-04 battery Clips
Electrical (additional)
Reverse drain Id < 0.5mA
Max input rating 90 - 264Vac 47-63Hz
Output volt range 0.5V - 14.4V @ 1A; 14.5V - 22V @ 0.2A
Protection Input AC fuse: 3A 250V (non accessible)
Protection output AUTOMATIC: reverse polarity; no output if no battery is connected;
limited output current (1A max).
Origin
Design copyright
& trademark
TecMate (International) S.A., B-3300 Tienen, Belgium
www.tecmate.com

TecMate Optimate 4 Specifications

General

Output Voltage	12V
Charging Current	0.8A
Battery Capacity Range	3-50Ah
Desulfation	Yes
Weatherproof	Yes
IP Rating	IP54
Input Voltage	100-240VAC 50-60Hz
Battery Types	AGM, GEL
Type	Automatic
Protection Features	Reverse polarity, short circuit
