TECNA EVOLUTION 12K - Page 65

65
3650EVOLUTION - 3655 EVOLUTION
Pos. Qt. Codice
Pos. Q. Item
Pos. Q. Articl
e
Denominazione Descri
p
tion Dési
g
nation Denominación Bezeichnun
g
Pos. C. Códi
g
o
Pos. A. Kode
1
4
10943
Vite Screw Vis Tornillo Schraube
2
1
50293
Controllo Saldatura Control Unit Unité de contrôle Control soldadura Schweiss-Steuerung
3
1
36931
Pannello Panel Panneau Panel Panel
4
1
21055
Interruttore tripolare Three-pole switch
Interrupteur
tripolaire
Interruptor bipolar dreipolig.Schalter
5
1
21214
Protezione Protection Protection Funda Schutz
6
5
10005
Molla a tazza Belleville washer Ressort Belleville Resorte de platillo Tellerfeder
7
1
10164
Vite Screw Vis Tornillo Schraube
8
1
40443E
Trasformatore Transformer Transformateur Transformador Transformator
9
1
20950
Silenziatore Silencer Silencieux Silenciador Schalldämpfer
10
1
22869
Valvola proporzionale Proportional valve
Vanne
proportionnelle
Válvula
proporcional
Proportionalventil
11
3
20610
Raccordo Junction Joint Racor Anschluss
12
1
20345
Raccordo Junction Joint Racor Anschluss
13
1
20065
Raccordo Junction Joint Racor Anschluss
14
1
22030
Filtro Filter Filtre Filtro Filter
15
1
50220
Scheda Comando
Proporzionale
Board for
controlling prop.
valve
Carte commande
vanne
proportionnelle
Tarjeta mando
proporcional
Printpl.Proportional-
Steuerung
16
7
20925
Morsetto Clamp Borne Borne Klemme
17
1
20426
Morsetto terra Hearth clamp Borne de terre Borne tierra Erdungsklemme
18
1
50269
Scheda relè Board relè Carte relais Tarjeta relé Printpl.Relais
19
1
36944
Pannello Componenti Panel components
Panneau
composants
Panel
componentes
Panel Komponente
20
5
21075
Fusibile
Fuse
Fusible Fusible Sicherung
21
5
20919
Portafusibile Fuseholder Porte-fusible Portafusible Sicherungshalter
22
1
22257
Contattore Contactor Contacteur Contactor Schütz
23
4
10009
Dado Nut Ecrou Tuerca Mutter
24
8
10882
Vite Screw Vite Tornillo Vite
25
4
20716
Tappo Cap bouchon Tapa Kappe
26
8
10264
Molla a tazza Belleville washer Ressort Belleville Resorte de platillo Tellerfeder
27
1
22001
Trasformatore Transformer Transformateur Transformador Transformator
28
4
10029
Dado Nut Ecrou Tuerca Mutter
29
4
10483
Molla a tazza Belleville washer Ressort Belleville Resorte de platillo Tellerfeder
30
1
22223
Cavo flat Flat Cable Câble plat Cable plano Flachkabel
31
1
22138
Ventola Fan Ventilateur Ventilador Lüfterrad
32
1
1512
A
Controllo Control
Côntrole Control Steuerung
33
6
10389
Vite Screw Vis Tornillo Schraube
34
12
10008
Molla a tazza Belleville washer Ressort Belleville Resorte de platillo Tellerfeder
35
1
36932/1
Coperchio Cover Couvercle Tapa Deckel
36
6
10317
Vite Screw Vis Tornillo Schraube
37
4
10328
Vite Screw Vis Tornillo Schraube
38
1
33637
Passacavo Cable guide Passe-câble Pasaborne Kabelschuh
39
1
71365
Cavo inverter inverter cable câble inverter Cable inverter Kabel Inverter
40
1
36930
Base testa Head cover
Base tête Base cabezal Gehäuseunterteil
41
1
22946
Connettore Femmina Female connector
Connecteur
femelle
Conector hembra Stecker
22947
22948
43
4
10133
Vite Screw Vis Tornillo Schraube
44
6
20033
Fascette Clamps Collier de serrage Abrazaderas Schellen
45
6
30842
Resca Junction Raccord Pitorro Nippel
46
1
22910
Passaparete Junction Passe-mur Pasapared Wanddurchgang
47
4
10030
Rondella Washer Rondelle Arandela Scheibe
48
4
10059
Vite Screw Vis Tornillo Schraube
49
1
20407
Passacavo Cable guide Passe-câble Pasaborne Kabelschuh
50
1
36600
Targa Plate Plaque Placa Typenschild
42
Connettore Connector Connecteur Conector Stecker1
