INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01
RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
− Connect the terminal on the lower left-hand side marked with the international symbol a connector
with a nominal cross section <10 mm2. All the appliances installed and the earth system of the building
shall be connected like this.
ATTENTION!
Cut the tension before to make the connection and/or maintenance .
2.2.2 CONNECTION TO WATERWORKS
− Water inlet pressure must be between 50 and 300 kPa, otherwise install a pressure regulator on the line
before the appliance.
− Install a cut-off valve for each supply on the line before the appliance.
− Water connections are fitted in the lower part on the left-hand side of the appliance.
− Make connections according to regulations currently in force.
2.2.3 GAS CONNECTION PROCEDURES
The choice of the gas piping depends on the diameter required for the type of gas, appliance and installation
and should be performed in conformity with current regulations.
Before making the connection, thoroughly clean the gas tube.
Impurities could affect the operation of the machine.
It is recommended that the installation of a pressure regulator (one for each machine),
to stabilize the pressure of the inlet gas.
The diameter of the connections is shown in "TECNICAL DATA"
The point of connection is shown in the "LAYOUT CONNECTIONS"
The gas feed plant can either be fixed or be disconnected; if flexible pipes are employed they must be made
from stainless material and not be affected by corrosion.
If sealing materials are used for connections, they must be certified and approved for the purpose.
Once the appliance has been connected, carry out a leakage test on all the fittings connecting the appliance to
the plant. It is advisable to use a leakage spray, otherwise treat the parts with a foam that does not produce
corrosion; no bubbles should develop. Carry out the leakage test also on the rapid cut-off valve.
Flames are strictly prohibited for leakage tests!
