1.7 TECHNICAL DATA
B8FXGN9 – B8MFXGN9
B8FIGN9 – B8MFIGN9
B12FXGN9 – B12MFXGN9
B12FIGN9 – B12MFIGN9
TECHNICAL DATA (DIMEMSIONS)
Equipment dim.A
mm
800
1200
Equipment dim.B
mm
900
900
Equipment dim.H
mm
900
900
Equipment dim.H2
mm
1630
1630
TECHNICAL DATA (FUNCTIONALITY)
Pan dimension A
mm
698
1098
Pan dimension B
mm
564
564
Pan dimension H
mm
200
200
Pan area
dm²
39
62
Overvall volume
lt
81
127
Useful volume
lt
60
100
Temperature
°C
45÷295
TECHNICAL DATA (INSTALLATION)
Gas power
kW
20
30
Gas connection
Ø"
3/4"
3/4"
Water pressure
kPa
50÷300
Hot water inlet
Ø"
1/2"
Latent heat emission
W/kW
450
Direct heat emission
W/kW
450
Moisture emission
g/h /kW
630
Sound level
dbA
< 70
M
Electric power
kW
0,2
Voltage/Input (standard)**
V
220-240 V 1N 50/60Hz
Cable connection ***
mm²
3 X 1,5
TECHNICAL DATA (STORAGE/MOVEMENT)
Packaging dim.A
mm
1070
1300
Packaging dim.B
mm
870
1050
Packaging dim.H
mm
1270
1220
Volume
m³
1,215
1,68
Net weight
kg
144
217
Gross weight
kg
169
255
**Verify on data plate - ***Cable for standard tension
