INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01
RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
− Unplug the appliance in case of failures or improper operation.
− Apply exclusively to a service centre for repairs or maintenance.
− Any important information about the appliance required for technical service is contained in the technical
data plate (see figure “View of appliance”).
− If technical assistance is required, the trouble must be described in as much detail as possible, so that a
service technician will be able to understand the nature of the problem.
− Gloves should be worn to protect the hands during installation and maintenance operations.
Follow the fire prevention regulations very carefully.
- Not used absolutly as frying mode.
- Follow the fire prevention regulations very carefully.
- Never use as a grill or a griddle.
- Never use an empty tank.
- Make sure that the boil does not leave the tank empty
− Main structure in steel with adjustable height feet.
− Exterior and top finish entirely made of stainless steel .
− Stainless steel vat lid, with bottom in INOX (AISI 304) in model
− Lid in stainless steel, hinged and spring balanced in all opening positions.
− Heating of the vat by burners in stainless steel, resistent to mechanical stress and thermal shocks.
− Gas is supplied through a multiple thermostatic valve.
− The main burner is lit by means of the pilot .
− Switch off the main burner when the pan is overturning
− Hand tilting of the pan
− Motor tilting pan
− Optional (cod.BAM0010) by-pass motorized tilting.
The appliance is equipped with:
− Thermostatic gas valve.
− Pilot burner ignition button
− Ignition of the pilot burner incorporated in the gas valve
− Control knob for temperature regulation.
− Filling of the pan by means of a tap placed on the front panel.
− Tilting handwheel
− Motorized tilting selector
