Tecnoinox B8FXGN9 - Page 32

INSTRUCTION MANUAL FOR INSTALLATION, MAINTENANCE AND USE Rev-01
31 GB
RECTANGULAR BRATT PANS GAS TYPE “BR8G080I - BR8G080I.M” “BR9G090I –
BR9G090I.M” “BR1G120I – BR1G120I.M” “BR1G150I – BR1G150I.M” “BR1G160I –
BR1G160I.M” “BR1G200I – BR1G200I.M”
6.9 FIG. CONTROLS
LEGEND:
1
Control knob
4
Vat water feed tap
2
Operating thermostat
5
Up/down selector
3
Peephole
6
Tilting handwheel
