Installation
D
C
C
D
Phase 3
- Take the air deviator D and make two holes as shown in the pho-
tographs.
- Secure the duct fixing bracket to the air deviator D as shown in
the photograph.
Phase 4
- Carry out final fixing of the air deflector D to the wall with a
fixing screw as shown in the photograph.
Phase 4
D


Phase 3
Ø 6
