Tecnowind EAGLE - Page 17

- 17 -
Phase 7
Phase 7
- Extend the upper decorative duct as far as bracket C and fix it in
place using screws X.
Installation


C
Phase 5
D
F
G
Phase 6
Phase 5
- Connect the flexible pipe (not supplied) to the deviator D.
- Fix the flexible pipe onto the connector flange G.
Phase 6
- Take care not to scratch the duct; wear gloves when removing
the protective lm.
