TECO 22 User Manual

22 User’s manual - TECO 22 - 23 - 25 - 27 Special
WARNING
Before proceeding with any adjustment or maintenance activity, disconnect the machine from
the air supply and electrically insulate the machine by means of an omnipolar disconnection
device. Make sure that all the mobile parts are locked.
CAUTION
In case of replacement of the power supply cable, follow the indications listed in the table
below for the most appropriate cable choice:
SUPPLY CABLE TYPE NR OF WIRES WIRE SECTION
400/3/50
400/3/60
230/3/50
230/3/60
200/3/50
200/3/60
FROR 450-750V
UNEL 35011
3 - phase
1 - grounding 1mm
2
240/1/50
230/1/50
220/1/60
FROR 450-750V
UNEL 35011
1 - phase
1 – neutral
1 - grounding
1,5mm
2
115/1/60
UL 1569 300V
105°C
1 - phase
1 – neutral
1 - grounding
AWG 14
CAUTION
Do not remove or modify any parts of this equipment except in the case of service operations.
DANGER
When the machine is disconnected from the air supply system, the devices marked with the
warning sign shown above may remain pressurised.
- The lter+regulator+lubricator (Teco 27 Sp.) is equipped with a semiautomatic condensation drain
device. This device operates automatically whenever the compressed air supply to the machine
is cut off. Drain the condensation manually (push-button d, g 22 ) when the level exceeds the
mark X, g. 22.
- Clean the top plate of the turntable every week: remove any accumulated dirt and clean with
environmentally-friendly solvents.
- Monthly checks (Teco 25 - Teco 27 Sp.):
• Clean the arms of the tool-carrying head, the bead breaking unit and the relative travel screws
with environmentally-friendly solvents only. Lubricate.
• Check the oil level in the air lubricator (g. 22) and, if necessary, top up with non-detergent
SAE20 oil to the indicated level Z.
• Clean with a dry cloth. Avoid contact with solvents.

TECO 22 Specifications

General

Brand	TECO
Model	22
Category	Tyre Changers
Language	English
