User’s manual - TECO 22 - 23 - 25 - 27 Special 23
• Check the oil ow-rate through the transparent cover K (correct ow-rate: 1 drop of oil every
4 bead breaking cycles). Adjust if necessary by turning the set screw Y g. 22.
- Monthly checks (Teco 22 - Teco 23):
• Clean and lubricate with naphta the horizontal arm and mounting bar.
• Disconnect the machine from the pneumatic circuit.
• Remove cap 1 and let a few drops of non-detergent (SAE 20) in using an ampoule.
• put cap 1 back on and tighten rmly.
• Check the stretch of the motor/reduction gear driving belt; using the machine, such belt
may become loosen and worn out.
CAUTION
Keep the working area clean.
Never use compressed air, jets of water or solvent to remove dirt or deposits off the machine.
When cleaning, take care not to create and raise dust as far as possible.
22
a
b
c
e
d
x
