4-21
12 : Up Command
13 : Down Command
14 : Main/sub Control Signal Select
15 : PID Function Disabled
16 : Integration Value Resets to Zero
17 : Reset
18 : KEB function
19 : Auto _ Run Mode
20 : Counter Trigger Signal
21 : Counter Reset
A. The terminals S1- S6 on terminal block (TM2) are multifunction input terminals. The 22 functions
shown above can be set for these terminals.
B. Function Description for 1-00~05：
1. 01-00~05=0/1(Forward/Reverse/Stop)
As forward command is ON, the inverter runs and stops when the command is OFF. The 1-00
factory setting is forward.
As reverse command is ON, the inverter runs and stops when the command is OFF. The 1-01
factory setting is reverse.
2. 01-00~05=2/3/4 (Frequency Command 1/2/4 at 3-02/3-03/3-05)
When External multifunction input terminals are ON, the inverter is operates at the preset speed and
the duration is determined by the time the input is ON. The corresponding preset frequency will be
according to preset value of parameters 3-01 to 3-07 and in relation to the operation of input
terminals 1 to 3. as shown in the table below:
Output frequency
preset value
Multifunction terminal 3
Preset value =4
Multifunction terminal 2
Preset value =3
Multifunction terminal 1
Preset value =2
3-01 0 0 0
3-02 0 0 1
3-03 0 1 0
3-04 0 1 1
3-05 1 0 0
3-06 1 0 1
3-07 1 1 0
3-08 1 1 1
3. 01-00~05=5/6(Forward/ Reverse JOG)
When Jog operation, is selected, the inverter operates at the Jog acceleration and
deceleration times. The corresponding jog frequency parameter is shown below:
The priority order of frequency : Jog Speed→Preset Speed→Keypad frequency or
external frequency signal
4. 01-00~05=7 (Acc/Dec time selection)
This input selects the acceleration 1/ deceleration 1 or acceleration 2/ deceleration 2.
5. 01-00~05=8 : External Emergency Stop.
The inverter will decelerate to stop by 10-06 setting and Flash E.S as the emergency stop signal
is received regardless of 04-01 setting. After the emergency stop signal is removed, turn the
RUN switch OFF and then ON again, or press the run key in keypad mode, the inverter will
restart again up and ramps up to the command frequency.
