TECO E310-201-H User Manual

6-1
Chapter 6 Peripherals Components
6.1 reactor specification at Input side
AC inductance at input side DC reactor specification at input side
Model
Current (A) Inductance (mH) Current (A) Inductance (mH)
E310-2P5-XXX 2.5 4.2 3.1 5.65
E310-201-XXX 5.0 2.1 4.5 3.89
E310-202-XXX 10.0 1.1 7.5 2.33
E310-401-XXX 2.5 8.4 2.3 15.22
E310-402-XXX 5.0 4.2 3.8 9.21
E310-403-XXX 7.5 3.6 5.2 6.73
E310-405-XXX 10.0 2.2 8.8 3.98
6.2 Braking unit and braking resistor
Braking resistor Specification
Inverter
Model
Suitable
Motor
Capacity
(HP)
Suitable
Motor
Capacity
(KW)
(W) (Ω)
Number
used
Braking resistor
Duty Cycle (%)
Braking torque
(%)
2P5 0.5 0.375 60 200 - 8 218
201 1 0.75 60 200 - 8 119
202 2 1.5 150 100 - 10 119
401 1 0.75 60 750 - 8 125
402 2 1.5 150 400 - 10 119
403 3 2.2 200 250 - 8 128
405 5 3.7 300 150 - 8 127
※ Formula for brake resistor: W= (Vpnb * Vpnb) * ED% / R
1. W: braking resistor power (Watts)
2. Vpnb: braking voltage (220V=380VDC, 440V=760VDC)
3. ED%: braking effective period
4. R: braking resistor rated ohms
