4-17
4.4 Parameter Function Description
Group0- The basic parameters group
00-00 : Control Mode 0 : V/F mode 1 : Vector mode (General Purpose)
To select the appropriate vector control mode or V/F mode according to the load characteristics.
1. If V/F mode is selected, please set parameters, group5 to comply with the load features.
Vector is best suited to control the general load or rapidly-changed torque load.
00-01 : Volts/Hz Patterns (V/F) = 0 ～ 18
1.00-01= 0 ~17, V / F Pattern. (Refer to group5)
2.00-01=18，Flexiable V/F pattern, programmable according to parameters 05-04～05-09.
00-02 :Motor rotation = 0 : forward 1 : reverse
Note：when10-01is set to 1, 00-02 is not set to1
00-03 : Main Run Command Source Select
=0 : Keypad =1 : External Run/Stop Control
=2 : Communication
00-04 : Alternative Run Command Source Select
=0 : Keypad =1 : External Run/Stop Control
=2 : Communication
1. 00-03/00-04=0, the inverter is controlled by the keypad.
2. 00-03/00-04=1, the inverter is controlled by the external terminals, and the Stop key for emergency
stop is operational. (Refer to 04-02 description)
※
Note: 00-03/00-04=1,please refer to parameter 04-03，04-04，04-06，04-07 for detailed description
in order to ensure safety of operators and machines.
3. 00-03/00-04=2, the inverter is controlled by Communication.
4. When 01-00 ~ 01-05 is set 10（Main/Alt Control Signal Select）,if the terminal is ON, the inverter is
controlled by parameter 00-03,if the terminal is Off, the inverter is controlled by parameter 00-04.
00-05 : Main Frequency Command Source Select
=0 : UP/DOWN of Keypad
=1 : Potentiometer on Keypad
=2 : External AVI Analog Signal Input
=3 : External Up/Down Frequency Control
=4 : Communication setting Frequency
00-06 : Alternative Frequency Command Source Select
=0 : UP/DOWN of Keypad
=1 : Potentiometer on Keypad
=2 : External AVI Analog Signal Input
=3 : External Up/Down Frequency Control
=4 : Communication setting Frequency
1. Please refer to description of parameter group 01-00 ～ 01-05 (multifunction input terminals) for
the function Up/Down terminal.
2. The priority in reading frequency is Jog> preset speed>▲▼ on keypad or Up / Down or
communication control.
3. When 01-00 ~ 01-05 is set 14（Main/Alt Frequency Command Select）,if the terminal is ON, the
inverter frequency command is set by parameter 00-05,if the terminal is Off, the inverter
frequency command is set by parameter 00-06.
