9-3
200V Class
400V Class
Servo Drives for
JSDAP-□□□□
10A 15A 20A 30A 50A3 75A3 100A3 150A3 200A3 300A3 25B 35B 50B 75B 100B
Output
Type
Phase A, B, Z Line Drive /Phase Z Open Collector
Position Output
Encoder
Ratio
Pulse Output: 1 ~ encoder—pulse numbers (any arbitrary values set by Internal
parameters)
Digital Input
[NPN/
PNP]
Optional
Input
To 12
Ports
31 Types of Optional Functions
Fix
Output
to 4
Ports
Fix Output Alarm Code
Digital Output
【Photocoupler】
Optional
Output
to 4
ports
17 Types of Optional Functions
Input/ Output Signal
Analog Monitor
Output
Optional
Output
to 2
ports
12 Types of Optional Functions (0~±10Vdc)
Indoor (avoiding direct sunshine)
Installing Location
no erosion air (avoiding oil gases, inflammable gas and dust)
Altitude
Sea level 1000m below
Temperature
Operating Temperature 0~ 50℃, storage Temperature: -20 ~ +65℃
Humidity
Operating, storage below 90% RH
Environment
Vibration
10 ~ 57Hz：20m/s
2
; 57 ~ 150Hz：2G
CE Declaration In compliance with EN61800-3 and EN61800-5-1
Certifications
UL Certification
UL508C
