Instruction Manual
10
A
V
ZERO
V
HOLD
OFF
A
100A600V CAT II
300V CAT III
600V CAT II
600V
COM
4.5 Resistance measurement:
Switch the function selector to
range.
Connect red test lead to “+” terminal and black one to the
“ COM ” terminal.
Connect tip of the test leads to the points where the value
of the resistance is needed.
Read the Ohm value from the LCD panel.
Note:
When measuring resistance value from a circuit, make
sure the power is cut off and all capacitors are
discharged.
