TECPEL DCM-043 - Table of Contents

CONTENTS
TITLE PAGE
I. Safety Information
………………………………….... 1
Environmental Conditions…………………………….…..
1
Explanation of Symbols……………….………………….
1
II. Specification
……………………………………….…… 2
General Specification…………………………………….
2
Electrical Specification…………………………………....
3
III. Instrument Familiarization
………………………… 4
Symbol Definition…………………………………………..
4
Instrument Familiarization………………………………...
4
Button Instruction…………………………………………..5
IV. Measuring Instruction
…………………...………….. 6
4.1 ACA measurement………………………………….
6
4.2 DCA measurement……...………………………….
7
4.3 ACV measurement……….…………………………
8
4.4 DCV measurement…………...……………….……
9
4.5 Resistance measurement……………...…………
10
4.6 Continuity Test……………………………………...
11
4.7 Analog Signal Output………………………………12
V. Battery Changing
……………………………………. 13
VI. Maintenance
………………………………………….. 13
