TECPEL DCM-043 - Button Operation Instructions; Zero Button Operation; Hold and Peak Hold Functions

Instruction Manual
5
○
1
Current Sensing Clamp
○
6
Positive input terminal
○
2
Safety protection ring
○
7
Function select dial
○
3
Clamp opening handle
○
8
Peak / Data hold button
○
4
LCD display
○
9
Zero button
○
5
COM input terminal
Button Instruction:
 Zero Button
Press Zero button to enter the Zero mode, “
△
” Annunciate
will appear and Zero the display. The reading is stored as
reference value for subsequent measurement.
Press the Zero button again, to exit the zero mode.
 Data Hold & Peak Hold Button
To activate the Data Hold feature, press and hold the
“ Hold ” button.
To de-activate the Data Hold feature, press and hold the
“ Hold ” button again.
To activate the Peak Hold feature, press and hold the
“ Peak ” button until the symbol displays.
To deactivate the Peak feature, press and hold the “ Peak ”
button for 2 seconds.
The meter will return to normal mode operation.
Note:
This meter is built with peak hold function at ACA,
DCA, ACV, DCV ranges.
 Disable Auto power off
Press and hold “ ZERO ” button and then the power on the
meter, the symbol will disappear.
