TECPEL DCM-043 - Instrument Familiarization Overview; Display Symbol Definitions; Physical Component Identification

Instruction Manual
4
III. Instrument Familiarization:
Symbol Definition:
Instrument Familiarization:
Voltage Indicator
Ampere Indicator
Continuity
Peak Hold
Low Battery
Alternate/Direct Signal
Digital Reading
Auto Power Off
Indicator
Data Hold
Relative Indicator
5
4
6
3
2
8
1
7
9
HOLD
600V CAT II
ZERO
V
V
A
A
OFF
100A
300V CAT III
600V CAT II
COM
600V
