Instruction Manual
3
Electrical Specification:
(
Ⅰ
) The accuracy specification is defined as
±
( …%reading
＋
…count ) At 23
±
5
℃
,
≦
80 %RH
ACA (Autorange)
Range Resolution Accuracy ( 50Hz~500Hz) Overload Protection
10A 1mA
80A 10mA
2%+10
80~100A 10mA 3.5%+10
150Arms
Accuracies are specified from 5% to 100% of range
DCA (Autorange)
Range Resolution Accuracy Overload Protection
10A 1mA
80A 10mA
2.5%+10
80~100A 10mA 4.5%+10
150Arms
Accuracies are specified from 5% to 100% of range
ACV
Range Resolution Accuracy (50Hz~500Hz) Overload Protection
600V 0.1V 1.5%+5 660Vrms
DCV
Range Resolution Accuracy Overload Protection
600V 0.1V 1%+2 660Vrms
Ohm (
Ω
)
Range Resolution Accuracy MAX Test Voltage Overload Protection
10K
Ω
1
Ω
1%+3 3V
DC
600Vrms
Continuity (
)
Range Active Region MAX Test Voltage Overload Protection
<100 Ohm
3V
DC
600Vrms
(Ⅱ) Analog output: ( for ACA & DCA range)
10 mV/Amp (20KHz at ± 3dB)
Accuracy: ± (4.5% reading + 0.5mV)
Output impedance: approx 3KΩ
Overload protection: 600 Vrms
