RAINBOW
》
Product Manual
V1.0
need to be treated as follows: 1, check the top of the department
whether there is foreign body jammed, 2, check the belt and
coupling is loose, 3, into the "top Department test procedure",
check the top department motor is normal work. If the motor does
not turn, change the motor; if there is no "off" signal, adjust
the clearance between the "off" sensor and the door, or replace
the sensor
1, check whether the ball pipe has foreign body stuck, if there
is removed; 2, emptying the pitch pipe, enter the "Browse all
input" test procedure, check L, M, n items have been shown green
items, if the need to replace the corresponding light eye.
3.2.Other fault analysis and treatment
1、
Frequent card ball, the wind can't blow the ball into the silo
A、Check the weight of the ball is over 8g, if there is more than change the color ball
B、Check if the site's voltage is too low
C、check the wind turbine and outlet whether there is debris blocked, if there is clean.
D、Check if dust is accumulated inside the blower and clean up if any.
2、Every time the game is over, the wind turbine have been working for a while.
A、check the game after the end of the ball recovery is still a ball stay, if there is
a proper reduction in the number of balls or increase the game time.
B 、The ball recovery port detects whether the light eye has debris or dust shielding,
if any, clean.
3、Dot-matrix screen flower screen, irregular flicker
A、check the line group is loose
B、 Replace the dot matrix screen
3.3.Machine structure diagram
3.3.1. Dot Matrix Screen Component:
Dot Matrix Screen Unit board
