N O T I C E - I M P O R T A N T
TED MODEL 1001 OPERATIONAL LIMITATIONS
• TED Model 1001 is only suitable for use on 120/240V single-phase 60Hz services
• TED Model 1001 is only suitable for services of 200 AMPS or less. (For 400 amp service,
see website for details on TED Model 1002)
• TED Model 1001 is only suitable for use with services with a single service disconnect
(For services with two disconnects, see website for details on TED Model 1002)
• TED Model 1001 is only suitable for services with maximum 350 MCM Conductors
• TED Model 1001 RDU is only approved for use with the following TED accessories:
• TED Model 1001 MTU (Measuring Transmitting Unit)
• TED Model QX 200-CT (Current Transformers)
Use with any other product will void warranty, and may cause an electrical or re hazard.
SAFE OPERATING RANGE AND CONDITIONS:
Use
Temperature
Relative Humidity
Altitude
Voltage
Indoor/Dry
10° - 40°C
< 80%
< 3,000M
100-130 V
RDU
Indoor/Outdoor Dry
5° - 40°C
< 90%
< 3,000M
100-130 V
MTU CT’s
Indoor/Outdoor Dry
5° - 40°C
< 90%
< 3,000M
100-600 V
If any of the following are true, this version of TED WILL NOT work:
• If you have a 3-Phase service, TED Model 1001/1002 WILL NOT work.
• If you have 230V 50Hz service typical in most areas outside North America, TED Model
1001/1002 WILL NOT work.
• If your main circuit breaker or fuse panel is larger than 200 Amps, TED Model 1001 WILL
NOT work. If it is 400Amps or less, TED Model 1002 is suitable.
• If you have more than one main circuit breaker or switch, TED Model 1001 WILL NOT
work. If you have 2 Main Circuit Breakers of 200Amps each, TED Model 1002 is suit-
able.
• If your main service circuit conductors (wires) are larger than 1-inch diameter, TED Model
1001/1002 WILL NOT work.
• Other TED models will be available soon for these applications. Please see our web site
for details.
