TeeJet 844-AB - Pressure Transducer Maximum Rating

844-AB Sprayer control 10
Software 4.03
Figure 4-10: Pressure Transducer Low
Pressure Calibration
4.0
4.04.0
4.0
p
pp
p
ref
refref
ref
1 2 3 4 5 6 7 8 9 10 11 12
P
RO
Make sure the sprayer pump is turned “Off”
and there is no pressure in the system. Press
and release the Plus and Minus keys
simultaneously to activate the auto-calibration
feature. The message “ME S” will be
displayed. A count of “0” through “9” will
appear on the lower right portion of the
screen.
Figure 4-11: Pressure Transducer Low
Pressure Calibration (Continued)
3.9
3.93.9
3.9
160
160160
160
mes
mesmes
mes 9
99
9
1 2 3 4 5 6 7 8 9 10 11 12
P
RO
Once the display finishes counting, a number
close to 4.0 (+/- 0.2) should be displayed. The
low pressure value of the transducer is
calibrated. Press the Program key to advance
to the next step.
Figure 4-12: Pressure Transducer Low
Pressure Calibration (Continued)
3.9
3.93.9
3.9
p
pp
p
ref
refref
ref
1 2 3 4 5 6 7 8 9 10 11 12
P
RO
NOTE:
If a pressure transducer is not installed on
the system, skip this step by pressing the
Program key. Leave the default value at
“4.0”.
Pressure Transducer Maximum Rating
(P HI)
The Pressure Transducer Maximum Rating
establishes the maximum rating of the
pressure transducer. This number can be
found stamped on the pressure transducer. If
the transducer has a maximum rating of 145
psi (10 bar in SI mode) and the number is
shown on the display, advance to the next
step by pressing the Program key. If the
maximum rating is 363 psi
(25 bar in SI mode), use the Plus or Minus
keys to change the value. Press the Program
key to advance to the next step.
Figure 4-13: Pressure Transducer Maximum
Rating
145
145145
145
p
pp
p
hi
hihi
hi 9
99
9
1 2 3 4 5 6 7 8 9 10 11 12
P
RO
