Chapter 5 - System Setup
Additional steps for HC MODE
Faces per Section Setting
As HC mode calculates working width based
on the number of faces sprayed by each
section, additional steps are required to setup
these values.
Figure 5-1: Section 1 Faces Settings
1
11
1
sec
secsec
sec
1 2 3 4 5 6 7 8 9 10 11 12
P
RO
1
11
1 face
faceface
face
Use the Plus or Minus keys to adjust the
value.
Press the Program key to advance to the next
program step. This step will repeat for each
section.
