Before reading further, study the drawing below to familiarize yourself with the
important components of your Teeter FreeStep.
A GUIDE TO YOUR FREESTEP
21 Transport Wheels (2)
22 Leveling Feet (3)
23 Console
24 Media Rack
25 Water Bottle Holder (2)
26 Power Input
27 USB Charging Port
28 Front Crossbar
29 Forward Pivot Arm
1 Base
2 Rear Stabilizer
3 Console Support Bar
4 Console Wire
5 Console Post
6 Console Support Cover Set
7 Handle Support Tubes (2)
8 Lower Seat
9 Pedals (2)
10 Forward Pivot Cover Sets
11 Seat Back Assembly
12 Seat Pivot Cover Set
13 Handles (2)
14 Handle Cam Lock
15 Linkage
16 Seat Handle
17 Height Adjustment Lever
18 Seat Back Adjustment Lever
19 Lower Seat Adjustment Lever
20 Seat Post
FRONT
BACK
RIGHT
LEFT
2
1
26
16
3
25
27
19
20
9
22
21
15
10
5
18
11
29
12
7
28
24
23
13
14
17
6
8
4
* Speciļ¬cations may vary from this image and are subject to change without notice.
