A PPENDIX K: C LEAR P ATH -SC C ABLE
P INOUTS
This section contains pinout information for ClearPath-SC accessory
cables available through Teknic and Teknic distribution.
CPM-CABLE-CTRL-MU120
Cable description: ClearPath-SC I/O connector cable, double-ended,
straight through. Molex MiniFit Jr. 8-position connector to same.
wire entry view
5 - RED 8 - ORG
4 - BLU
3 - WHT
2 - BLK
1 - GRN
7 - BRN 6 - YEL
122"
Pin Assignments
Pin Color Name
1 GRN
2
3
4
5
6
7
8
BLK
SC Data - (from motor)
Input B +
Input A +
User Data +
(to motor)
Input B -
Input A -
User Data -
(to motor)
SC Data + (from motor)
WHT
BLU
RED
YEL
BRN
ORN
Factory
overmolded
connector
Standard
connector
CPM-CABLE-CTRL-MU120
CPM-CABLE-CTRL-MM660
Cable description: ClearPath-SC I/O connector cable, double-ended,
straight through. Molex MiniFit Jr. 8-position connector to same.
wire entry view
5 - RED 8 - ORG
4 - BLU
3 - WHT
2 - BLK
1 - GRN
7 - BRN 6 - YEL
662"
Pin Assignments
Pin Color Name
1 GRN
2
3
4
5
6
7
8
BLK
SC Data - (from motor)
Input B +
Input A +
User Data +
(to motor)
Input B -
Input A -
User Data -
(to motor)
SC Data + (from motor)
WHT
BLU
RED
YEL
BRN
ORN
CPM-CABLE-CTRL-MM660
