User’s Manual
8
2. Overview and specifications
2.1. Product overview
Ÿ TEKON 560 is a lightweight but robust handheld power analyzer designed for
routine and diagnostic testing on-site of power. It incorporates 7-inch wide
view touchscreen and uses rechargeable batteries.
Ÿ Allows you to monitor a variety of power parameters such as power, voltage,
current, harmonics, signal waveforms and phase diagram with added
convenience of being able to read the large LED screen
2.1.1. Features
Ÿ Captures three-phase power quality measurements
Ÿ Simultaneously measures active/reactive/apparent power, power factor, RMS
voltage/current, phase angle and neutral line current
Ÿ Supports a variety of wiring such as single-phase 2-wire, single-phase 3-wire,
three-phase 3-wire and three-phase 4-wire
Ÿ Displays voltage and current in waveforms and phase diagram
Ÿ Selectable excitation voltages: 5V, 10V, 40V
Ÿ Lightweight and sturdy handheld device that is easy to install and carry
Ÿ Easy-to-read 7-inch widescreen
Ÿ Touchscreen with user-friendly UIs
Ÿ Rechargeable batteries
Ÿ Facilitates a micro SD memory card slot (to 8GB capacity as standard) that
allows you to backup large volume of power survey data
