Tekon 560 - Nomenclature and Functions

User’s Manual
9
2.2. Nomenclature and functions
2.2.1. Appearance
No.
Function
Description
①
Power Button
Power On/Off Button
②
Adaptor socket
Socket used to be plugged into power outlet for
charging
③
Terminal for
line input
A power input terminal used to house the measurement
cable
④
SD socket
USB socket
A slot into which SD card is inserted to save data
Used to connect USB cable for communications
⑤
Display screen
LCD readout of the measurements (7-inch, 1024*600
pixels)
No.
Function
Description
①
Voltage input
terminal
A terminal for connection with
the lead for voltage testing
②
Clamp sensor
input terminal
A terminal for connection with
current clamp
