User’s Manual
11
Max. input voltage(Phase–Neutral):
1000Vrms
Max. input voltage(Phase–Phase):
1730Vrms
Phase-Neutral input impedance:
6 MΩ
Phase–Phase input impedance:
6 MΩ
AD converter
16 bit 8 channels,
simultaneous sampling
Sampling frequency
10.24k Samples/sec
Reference temperature
23°C±2°C
Temperature influence
25ppm/°C
2.3.6. Electrical specifications
■ Power Analyzer
Volt/Freq
Range
Resolution
Accuracy
Vrms (AC+DC)
1 ~ 300 V
1 ~ 6000 V
1 ~ 1000 V
0.1 V
0.1 V
1 V
± 0.25% rdg ± 0.2fs
± 0.25% rdg ± 0.2fs
± 0.3% rdg ± 0.2fs
Vpk
1 ~ 2000 Vpk
0.1 V 1 V
± 5%
Vrms½
1 ~ 300 V
1 ~ 6000 V
1 ~ 1000 V
0.1 V
0.1 V
1 V
± 0.5%
± 0.5%
± 0.6%
Vfund
1 ~ 300 V
1 ~ 6000 V
1 ~ 1000 V
0.1 V
0.1 V
1 V
± 0.25% rdg ± 0.2fs
± 0.25% rdg ± 0.2fs
± 0.3% rdg ± 0.2fs
V Crest Factor
1.0 ~ > 2.5
0.01
± 5%
Hz
42.5 ~ 69 Hz
0.1 Hz
± 0.1 Hz
