Tekon 560 - Page 15

User’s Manual
13
Harmonics
Range
Resolution
Accuracy
Harmonics
order (n)
DC, 1~50 Harmonic groups
Inter-Harmonics
order
Off, 1~50 Harmonic & Inter-Harmonic subgroups
V %f
0.0 ~ 100.0%
0.1%
± 0.25% ± n x 0.1%
V %r
0.0 ~ 100.0%
0.1%
± 0.25% ± n x 0.4%
V Absolute
0.0 ~ 1000 V
0.1 V
± 5% (*)
V THD
0.0 ~ 100.0%
0.1%
± 2.5%
A %f
0.0 ~ 100.0%
0.1%
± 0.25% ± n x 0.1%
A %r
0.0 ~ 100.0%
0.1%
± 0.25% ± n x 0.4%
A Absolute
0.0 ~ 600 A
0.1 A
± 5 % ± 5 digit
A THD
0.0 ~ 100.0%
0.1%
± 2.5%
W %f또는 %r
0.0 ~ 100.0%
0.1%
± n x 2%
W Absolute
Depends V nominal & Clamp Range
± 5% ± n x 2%
± 10 digit
W THD
0.0 ~ 100.0%
0.1%
± 5%
Phase acgle
-180° ~ +180°
1°
± n x 1°
