Tektronix 47E5A User Manual

Table 7 (cont)
Characteristics
Performance Requirements
VERTICAL SYSTEM (cont)
Step Response
Rise Time (0° C to +40° C) 3.5 nanoseconds or less.
Positive-Going Step
(Excluding ADD Mode)
Aberrations (0° C
to +40° C)
Position Effect
(0° C
to +40° C)
Negative-Going Step
ADD Mode Operation
76
465B/DM44 Operators
Supplemental Information
5-division reference signal centered
vertically, de coupled
at all deflection
factors, from a 25-ohm source with
VAR VOLTS/DIV control
in
calibrated detent position.
+4%,
-4%,4% p-p or less (5 mV to 2 V).
+6%, -6%, 6% p-p or less (5 V setting
only).
Total aberrations
less than +6%, -6%,
6% p-p; checked at 5 mV per division.
Add
2% to all positive-going step
specifications; checked
at 5 mV per
division.
Add
5% to all aberration specifications;
checked
at 5 mV per division.
@
I
I
I
I
I
1
I
I
I
