Tektronix 485

Replaceable Mechanical'Parts—485
Index Tektronix Serial/Model No. Mfr
No. Part No. Eff Dscont Qty 1 2 3 4 5 Name & Description Code Mfr Part Number
Fig &
2-26 352-0198-00
1
. . CONN BODY,PL,EL:2 WIRE BLACK
80009 352-0198-00
-27
131-0707-00
4
. . CONNECTOR,TERM.:0.48” L.22-26AWG WIRE
22526
75691-005
(ATTACHING PARTS FOR CKT BD)
-28 211-0021-00
2 SCREW,MACHINE:4-40 X 1.25 INCH.PNH STL
83385
OBD
211-0207-00
2
SCR,ASSEM WSHR:4-40 X 0.312 INCH,PNH STL
83385
OBD
644-0437-00
1
POWER SWITCH ASSEMBLY
-29
260-1368-01
2
. SWITCH,SENS:SPST,15A,250VAC 89265 A1-M1-3G1-6-33
(ATTACHING PARTS)
-30
220-0665-00
2
. NUT,PLAIN,HEX.:SLFLKG,4-40 X0.25",PLSTC
23050
OBD
-31
211-0020-00
2
. SCREW,MACHINE:4-40 X 1.125 INCH,PNH STL
83385
OBD
-32 214-1689-00
i
. ACTUATOR,SWITCH:
80009
214-1689-00
-33 214-1226-01
i
. SPRING,HLCPS:0.18 OD X 0.44 INCH LONG
80009
214-1226-01
-34 200-1318-00 i
. COVER,SW ACTR:
80009 200-1318-00
(ATTACHING PARTS)
-35 211-0101-00
2
SCREW,MACHINE:4-40 X 0.25" 100 DEG.FLH STL 83385
OBD
-36
210-0586-00
2
NUT,PLAIN,EXT W:4-40 X 0.25 INCH,STL 78189
OBD
1
CKT BOARD ASSY:A TRIGGER (SEE A8 AND A9 EPL)
. CONTACT,ELEC:0.46 INCH LONG
-38 131-0589-00
i
22526
47350
131-0608-00
9
. TERMINAL,PIN:0.365 L X 0.25 PH,BRZ GOLD,PL
22526
47357
-39 131-1003-00
7 . CONNECTOR BODY,:CKT CD MT,3 PRONG
80009
131-1003-00
136-0252-04 B010100 B091529
128
. SOCKET,PIN TERM:0.188 INCH LONG
22526
75060
-40 136-0252-04 B091530
B143774
125
. SOCKET,PIN TERM:0.188 INCH LONG 22526 75060
136-0252-04
B143775
105
. SOCKET,PIN TERM:0.188 INCH LONG 22526
75060
136-0514-00 B091530
1
. SOCKET,PLUG IN:MICROCIRCUIT,8 CONTACT
73803
C950802
136-0634-00 B143775
1
. SOCKET,PLUG-IN:20 LEAD DIP,CKT BD MTG 73803 C952002
-41
136-0461-00
2
. SKT.PL-IN ELEC:CKT CARD CONTACT 80009 136-0461-00
-42 214-0579-00
3
. TERM..TEST PT:0.40 INCH LONG
80009 214-0579-00
-43
200-1167-00 1
. COVER, XSTR: TEMP STAB FOR 2 TO-18 CS STYLE 80009 200-1167-00
(ATTACHING PARTS FOR CKT BD)
-44 211-0007-00
4
SCREW,MACHIME:4-40 X 0.188 INCH,PNH STL 83385
OBD
CKT BOARD ASSY: POWER SUPPLY (SEE A13 EPL)
. TERMINAL,PIN:0.365 L X 0.25 PH.BRZ GOLD,PL
-46 131-0608-00
35
22526
47357
-47 131-1003-00
4 . CONNECTOR BODY,:CKT CD MT,3 PRONG 80009
131-1003-00
-48
136-0183-00
6
. SOCKET,PLUG-IN:3 PIN,ROUND 80009 136-0183-00
-49
136-0252-04
B010100
B091529 69
. SOCKET,PIN TERM:0.188 INCH LONG 22526 75060
136-0252-04
B091530
58
. SOCKET,PIN TERM:0.188 INCH LONG
22526
75060
136-0220-00
B091530 2
. SOCKET,PLUG-IN:3 PIN,SQUARE
71785 133-23-11-034
136-0514-00 B091530
1
. SOCKET,PLUG IN:MICROCIRCUIT,8 CONTACT 73803 C950802
-50 136-0260-02 6
. SOCKET,PLUG-IN:16 CONTACT,LOW CLEARANCE
82647
C951601
-51
136-0263-04 35
. SOCKET,PIN TERM:FOR 0.025 INCH SQUARE PIN
22526 48059
136-0263-03 1
. SOCKET,PIN TERM:FOR 0.025 INCH SQUARE PIN
00779 86250-2
-52 136-0269-02 3
. SOCKET,PLUG-IN:14 CONTACT,LOW CLEARANCE
01295
C951401
-53 136-0461-00 3
. SKT,PL-IN ELEC:CKT CARD CONTACT 80009 136-0461-00
-54 214-0579-00 24
. TERM..TEST PT:0.40 INCH LONG
80009
214-0579-00
-55 214-1292-00 6
. HEAT SINK,ELEC:TRANSISTOR
05820 205-AB
-56 2
. TRANSISTOR:(SEE Q2066.Q2076 EPL)
(ATTACHING PARTS FOR EACH)
-57 211-0097-00 1
. SCREW,MACHINE:4-40 X 0.312 INCH.PNH STL
83385 OBD
-58
210-0406-00 1
. NUT,PLAIN,HEX.:4-40 X 0.188 INCH.BRS
73743
2X12161-402
(ATTACHING PARTS FOR CRT BD)
-59 211-0007-00
7
SCREW,MACHINE:4-40 X 0.188 INCH,PNH STL
83385
OBD
-60
131-1143-00
26 CONNECTOR,RCPT:CKT BD,5 PIN
80009 131-1143-00
-61
1
CKT BOARD ASSY: SWEEP GENERATOR (SEE A10 EPL)
131-0566-00 XB020000 1
. LINK,TERM.CONNE:0.086 DIA X 2.375 INCH L
55210 L-2007-1
-62 131-0589-00 1
. CONTACT,ELEC:0.46 INCH LONG
22526
47350
131-0608-00
10 . TERMINAL,PIN:0.365 L X 0.25 PH.BRZ GOLD PL
22526 47357
-63
131-1003-00
3
. CONNECTOR BODY,:CKT CD MT,3 PRONG
80009 131-1003-00
*A9 replaces A8 in 485-1 and 485-2 instruments.
9-11
REV. I APRIL 1978
