Tektronix DPO2012B User Manual

Getting Acquain
ted with the Oscilloscope
9. The trigger rea
dout shows the trigger
source, slope, level, and frequency for
an Edge trigger. The trigger readouts
for other trig
ger types show other
parameters.
10. The horizontal position/scale readout
shows on the top line the horizontal scale
(adjust with
the Horizontal Scale knob).
With Delay Mode on, the bottom line
shows the time from the T symbol to the
expansion p
oint icon (adjust w ith the
Horizontal Position knob).
Use horizontal position to insert added
delay betw
een when the trigger occurs
and when you actually capture the data.
Insert a negative time to capture more
pretrigge
r information.
With Delay Mode off, the bottom line
shows the time location of the trigger
within th
e acquisition, as a percentage.
11. Measurement readouts show the
selecte
d measurements. You can select
up to four measurements to display at
one time.
A
symbo
l appears instead of the
expected numerical measurement if a
vertical clipping condition exists. Part
of the w
aveform is above or below the
display. To obtain a proper numerical
measurement, turn the vertical scale
and po
sition knobs to make all of the
waveform appear in the display.
12. The auxiliary waveform readouts show
the vertical and horizontal scale factors
of th
e math and reference waveforms.
13. The c hannel readout shows the channel
sca
le factor (per division), c oupling,
invert, and bandwidth status. Adjust with
the Vertical Scale knob and the channel
1, 2
, 3,or4 menus.
36 MSO2000B and DPO2000B Series Oscilloscopes User Manual
