Analyze Wavefor
mData
2. Push Add Measu
rement .
Add Mea-
surement
Remove
Measure-
ment
Indicators
Gating
Screen
High-Low
Method
Auto
Bring
Cursors
On Screen
Configure
Cursors
3. Turn multipurpose knob a to se lect the
Measurement Type of Snapshot All.
4. Push OK Snapshot All Meas.
OK
Snapshot
All Meas
94 MSO2000B and DPO2000B Series Oscilloscopes User Manual
